Processing container 4×2,2 – H&H Cooling Systems

This 4×2.2m processing container is the best solution when you’re looking for a new way to process, cool, and store wild game.

The 4×2.2 model is 20 cm wider than the 4×2 model.

External width: 220 cm

Internal width: 200 cm

Our containers are made from 100 mm-thick polyurethane foam layered panels, covered on both sides with a metal sheet (new XPS technology, no corrosion, long-lasting, easy to clean, easy to move, no visible installation, no silicone, superb isolation).

Thanks to the special construction, all units are resistant and weatherproof. The steel frame is galvanised and powder-coated, ensuring excellent corrosion protection and longevity. At the same time, the containers are lightweight and mobile.

The integrated forklift operating slots in the steel frame can be used for unloading or moving with a forklift, or the container can be easily moved with a crane using the lifting hooks.

Our container units set new standards for processing and cooling wild game.

Each processing container consists of two separate spaces:

Processing room – a place for processing wild game.

The standard equipment includes:

A stainless steel rail system with Euro hooks (5 pieces)
Hygiene wall
5-litre boiler (2000W)
Water hose
Knife magnet
1.5 m processing table with hook station
Wall shelf
First-aid kit
Stainless steel waste
1 spreading hook

Cooling room – a place for cooling and storing wild game. With the high-quality Embraco Aspera cooling unit, 10 cm-thick walls, and specialised cooling doors, a minimum temperature of -5°C can be set (regardless of the outdoor season).

The cooling room in the 4×2.2 unit provides space for:

5 wild boars,
4 deer, or
7 roe deer.

Each model can be ordered in standard or mirrored-configured versions. Detailed basic and additional equipment can be found on the website.

Exterior colour and flooring options:-

Green RAL 6005 or white RAL 9010

Smooth stainless steel flooring, R13 aluminium check plate, or self-leveling polyurethane resin flooring.

Delivery: we deliver our containers to any location in the United Kingdom.

Equipment

Hygiene wall made of stainless steel
Knee-operated sink
5-litre boiler (2000W) providing hot water up to 50°C
Water hose, large back wall, and paper towel dispenser
Soap and disinfectant dispensers (1L each)
Knife magnet
Dressing Table (Stainless Steel): 1.5 m-long with brown PE plastic and hook station
Wall shelf and first-aid kit
Double roof – additional roof made of corrugated sheet metal
Rail system made of acid-resistant steel for hanging hooks
Hook set: 5 Euro-hooks with side hooks (DIN 5047)
Electric winch with a lifting capacity of 300/600 kg above the entrance to the unit
Embraco Aspera Cooling Unit
Electronic control for adjusting temperatures from +10°C to -5°C
Electrical panel with IP65 protection class and a power meter
LED lighting for both external and internal areas
230V-AC power supply
Key set for both doors (2x)
Hermetically sealed electrical sockets, 230V IP65-rated
Main switch
Spreading hook: 1 piece
Stainless steel waste bucket
Insulated pipes inside the cooling container
Key safe
Forklift slots integrated into the frame for easy loading/unloading
Floor drain, Ø50mm
Water connection 1/2–inch inlet (DN 15)
Hygiene wall drain, Ø40mm
Power connection 230V, 16A
Certified structural integrity
2-year manufacturer’s warranty

We also produce cooling containers and cooling and processing containers according to individual specifications/requests.

Specification

Size	Length [L]	Width [S]	Height [H]
External dimensions	400 cm / 13,1ft	220 cm / 7,2ft	295 cm / 9,7ft
Internal dimensions – processing room	270 cm / 8,9ft	200 cm / 6,6ft	250 cm / 8,2ft
Internal dimensions – cooling room	100 cm / 3,3ft	200 cm / 6,6ft	250 cm / 8,2ft
Rail height:	228 cm / 7,5ft
Total length with front and rear roof:	570 cm / 18,7ft
Weight:	approx. 1400-1500 kg (depending on selected equipment)
